Q601
6.5 Inch Ultimate Handheld Windows Mobile Computer
Function
Introduction
The Q601 is a powerful and durable mobile device that fits in the palm of your hand. The 6.5” touch screen is large enough that you can read product or data, but the unit is small enough to fit in your pocket. The Q601 is IP65 rated and MIL-STD-810G drop and shock proof. The optional UHF Reader, built-in 1D/2D barcode scanner can be used to track inventory, for Barcode Administration, ID, and point-of-sale applications. Our range of durable Windows handheld devices provide effective hassle free rugged mobility for any workplace. Built to withstand the most demanding environments and equipped with the latest Windows OS, you can rely on these devices to provide you with the support that you need.
High Performance with powerful Intel processor
Powered by Intel's processor, the Q601 ultra-rugged windows tablet offers high performance and low power consumption for some of the most demanding professional-grade applications.With a footprint of 180mm X 85mm the Q601 is compact but no lightweight. The Intel N100 CPU, a new 6W 7nm 2023 CPU paired with 8GB of RAM gives you the juice to run Windows 10 properly.
COMPACT Design with the power to run Windows
Q601 ultra-rugged tablet is built to survive temperature changes, drops, shock, and vibration. The battery is easily to work whole work day and can be charged with the optional desktop cradle. Business rugged means you get a fully protected rugged handheld device. The Q601 is protected to meet the demands of work in the wild (mobile staff with slippery fingers). IP65 means dust and liquids are ok. Drops and knocks are ok too. Use in the arctic circle or on your artic lorry.
Built to Survive personal digital assistant
Using the Q601 is a breeze. The Q601 Windows smart terminal that combines design, toughness and innovation technology, 6.5" Rugged Tablet PC comes with 10 point capacitive touch screen. The touch panel itself is ruggedized to prevent cracks or scratches. Take pictures with the dual cameras (13MP rear, and 5MP front) and integrates high-speed wireless communication technologies so you can stay connected online anytime, anywhere: dual band Wi-Fi, Bluetooth, 4G LTE communication and many different kinds of satellites for more accurate positioning. Hosoton Q601 Ruggedized Tablet PC is built to enable mission-critical mobile worker productivity without compromise.
Unique Rugged Solution for Mobile Workforce
The Hosoton Industrial windows terminal Q601 shines when it comes to collecting and sharing all kinds of data. Snap a high-res photo and email it to a colleague, or wirelessly update your office database in real time. Work orders stay current and data stays safely stored, both on your device and in your preferred cloud system. Use this tablet's built-in u-blox GNSS receiver, gyroscope, compass and more, or attach your own tools, sensors and antennas. Stay wired through waterproof physical ports, connect via BT and NFC, or use the docking station which gives you extended I/O capabilities such as HDMI, Ethernet, and more.
| Operation System | |
| OS | Windows 10/11 home/pro/iot |
| CPU | Intel® ADL-N, N100 |
| Memory | 8 GB RAM /256 GB Flash |
| Languages support | English, Simplified Chinese, Traditional Chinese, Japanese,Spanish, German, French, Italian, Portuguese, Korean and multiple languages |
| Hardware specification | |
| Screen Size | 6.5 inch color 1600 x 720 display 400 nits |
| Touch Panel | Gorilla glass III with 10 points Capacitive Touch Screen |
| Buttons / Keypad | V+ -, Power, SCAN-KEY |
| Camera | rear 5 MP, front 13MP, with flash and auto focus function |
| Indicator Type | LED, Speaker, Vibrator |
| Battery | Rechargeable li-ion polymer, 5000mAh |
| Symbologies | |
| 2D | SE550 or Newland N1 |
| UHF Reader | M500, distance 3-6 meter |
| Others | NFC ,support ISO14443 TYPE A standard/Mifare |
| Communication | |
| Bluetooth® | Bluetooth®5.0 |
| WLAN | Wireless LAN 802.11a/b/g/n/ac, 2.4GHz and 5GHz Dual Frequency |
| WWAN | GSM: 850,900,1800,1900 MHzWCDMA: 850/1900/2100MHz
LTE:FDD-LTE (B1/B2/B3/B4/B5/B7/B8/B12/B17/B20) TDD-LTE (B38/B39/B40/B41) |
| GPS | GPS/BDS/Glonass, error range ± 5m |
| I/O Interfaces | |
| USB | USB-Type-C*1 support fast charging , USB 3.0*1 |
| POGO PIN | Bottom 8PIN POGOPIN *1 |
| SIM Slot | SIM card *2 or TF card*1 + SIM card *1 |
| Expansion Slot | MicroSD*1, up to 512 GB |
| Enclosure | |
| Dimensions( W x H x D ) | 180*85*22mm |
| Weight | 500g (with battery) |
| Durability | |
| Drop Specification | 1.2m, 1.5m with boot case ,MIL-STD 810G |
| Sealing | IP65 certified, MIL-STD-810G certified |
| Environmental | |
| Operating temperature | -20°C to 50°C |
| Storage temperature | - 20°C to 70°C (without battery) |
| Charging temperature | 0°C to 45°C |
| Relative Humidity | 5% ~ 95% (Non-Condensing) |
| What comes in the box | |
| The standard package contents | Q601 DeviceUSB Cable
Adaptor (Europe) |
| Optional Accessory | Hand StrapCharging docking
Vehicle cradle |
